Nodus ICT Solutions d.o.o

Safire SF-XVR8104S-4KL snimac

Šifra: 29467
MP cena: 29.063,00 rsd.
Web cena: 25.808,00 rsd.
Ušteda: 3.255,00 rsd.
Sve cene na prodavnici su izražene sa PDV-om.
 Količina

Safire SF-XVR8104S-4KL, 4 kanalni HDTVI/HDCVI/AHD/CVBS/ 4+4 IP snimač rezolucije snimanja 8MP (8FPS), Encoding capability: H.265+ High Efficiency Video Codec; Podržava Audio preko koaksijalnog kabla; PTZ kontrola (RS485/Coaxial); FullHD HDMI i VGA izlazi; 1 HDD SATA slot za interno skladištenje.



SPECIFIKACIJE:

Video compression H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding resolution 8 MP/5 MP/4 MP/3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame rate Main stream: ,8MP@8fps/5MP@12fps/4 MP@15fps/3 MP@18fps,1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N),Sub-stream: ,WD1/4CIF/CIF@25fps (P)/30fps (N)
Video bit rate 32 Kbps to 10 Mbps
Dual stream Support
Stream type Video, Video & Audio
Audio compression G.711u
Audio bit rate 64 Kbps
IP video input 4-ch (up to 8-ch) Up to 8 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras
Analog video input 4-ch BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection
AHD input 5 MP, 4 MP, 1080p25, 1080p30, 720p25, 720p30
HDCVI input 4 MP, 1080p25, 1080p30, 720p25, 720p30
CVBS input PAL/NTSC
Audio input 1-ch, RCA (2.0 Vp-p, 1 K?) / / Audio over coaxial from camera
Audio output 1-ch, RCA (Linear, 1 K?)
Two-way audio 1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input)
Synchronous playback 4-ch
HDTVI input 8 MP, 5 MP, 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25
VGA/HDMI output 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Remote connections 32
Network protocols TCP/IP, PPPoE, DHCP, Safire Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
Network interface 1, RJ45 10M/100M self-adaptive Ethernet interface
Network bandwidth 32Mbps
SATA 1 SATA interface
Capacity Up to 6 TB capacity for each disk
Alarm in/out N/A
USB interface 2 × USB 2.0
Power supply 12 VDC
Consumption (without HDD) <= 15 W
Working temperature -10 °C to +55 °C (+14 °F to +131 °F)
Working humidity 10% to 90%
Dimensions (W × D × H) 200 × 200 × 45 mm (7.9 × 7.9 × 1.8 inch)
Weights (without HDD) <= 1.16 kg (2.6 lb)
